Specifications
| CPU | LGA1700; Supports 14th/13th/12th Gen Intel® Core™, Pentium® Gold, Celeron®; L3 cache varies by CPU |
| Chipset | Intel® B760 Express Chipset |
| Memory | DDR5 4000–8000(O.C.) MT/s; 2×DDR5 DIMM up to 128 GB; Dual channel; ECC/Non-ECC Un-buffered DIMM; XMP support |
| Onboard Graphics | Intel® HD Graphics; D-Sub: 1920×1200@60Hz; HDMI 2.1: 4096×2160@60Hz; DisplayPort 1.2: 4096×2304@60Hz; Triple-display support |
| Audio | Realtek® Audio CODEC; HD Audio; 2/4/5.1/7.1-channel; S/PDIF Out |
| LAN | Realtek® 2.5GbE (2.5G/1G/100M) |
| Wireless | Realtek® Wi-Fi 6 RTL8851BE (2.4/5GHz, 11ax 80MHz); Bluetooth 5.3 |
| Expansion Slots | CPU: 1×PCIe 5.0 x16; Chipset: 1×PCIe 3.0 x1 |
| Storage | CPU: 1×M.2 PCIe 4.0 x4/x2 (2280); Chipset: 1×M.2 PCIe 4.0 x4/x2 (2280); 4×SATA 6Gb/s; RAID 0/1/5/10 |
| USB | Rear: 1×USB-C 3.2 Gen1, 3×USB 3.2 Gen1, 2×USB 2.0; Internal: 2×USB 3.2 Gen1, 4×USB 2.0 |
| Internal I/O | 24-pin ATX; 8-pin CPU; CPU fan; 3 system fans; 2×ARGB Gen2; 1×RGB; 2×M.2; 4×SATA; FP header; FP audio; SPDIF; USB 3.2 Gen1; 2×USB 2.0; TPM; Serial; Q-Flash Plus; Reset; Clear CMOS |
| Back Panel | 2×USB 2.0; PS/2; 2×antenna; D-Sub; HDMI; DisplayPort; 3×USB 3.2 Gen1; 1×USB-C 3.2 Gen1; RJ-45; 3×audio jacks |
| I/O Controller | iTE® Controller Chip |
| Monitoring | Voltage, temperature, fan speed, water flow; Fan fail warning; Fan control |
| BIOS | 128 Mbit AMI UEFI; PnP 1.0a; DMI 2.7; WfM 2.0; SM BIOS 2.7; ACPI 5.0 |
| Features | GIGABYTE Control Center; Q-Flash; Q-Flash Plus; Smart Backup |
| Software | Norton® Internet Security (OEM) |
| OS Support | Windows 11 64-bit; Windows 10 64-bit |
| Form Factor | Micro ATX (24.4 cm × 22.5 cm) |
