ASUS RT-AX58U V2 AX3000 Dual Band Mesh WiFi 6 Gigabit Router

Specifications

Network Standard
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6
Product Segment
AX 3000 (2402Mbps+574Mbps)
Coverage
Large homes
Data Rate
802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 300 Mbps
802.11ac : up to 867 Mbps
802.11ax (2.4GHz) : up to 574 Mbps
802.11ax (5GHz) : up to 2402 Mbps
Antenna
External antenna x 4
Transmit/Receive
2.4 GHz 2 x 2
5 GHz 2 x 2
Processor
1.5 GHz tri-core processor
Memory
256 MB Flash
512 MB RAM
Wi-Fi Technology
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80/160 MHz bandwidth
Operating Frequency
2.4 GHz / 5 GHz
Encryption
WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support
Firewall & Access Control
Firewall: SPI intrusion detection, DoS protection
Access control：Parental control, Network service filter, URL filter, Port filter
Management
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log
VPN Support
IPSec Pass-Through
PPTP Pass-Through
L2TP Pass-Through
PPTP server
OpenVPN server
PPTP client
L2TP client
OpenVPN client
WAN Connection Type
Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Ports
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4
USB 3.1 Gen 1 x 1
Features
Router app
MU-MIMO
Traffic Analyzer
Adaptive QoS
AiProtection Pro
Parental Control
Guest Network :
VPN server : PPTP Server, IPSec server
VPN client : PPTP client, L2TP client, OpenVPN client
NAT Pass-Through :PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay
Mac OS Backup
Enhanced media server (AiPlayer app compatible)
– Image : Jpeg
– Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg
– Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
AiCloud personal cloud service
3G/4G data sharing
Printer Server
– Multifunctional printer support (Windows only)
– LPR protocol support
Download Master
– Support bt, nzb, http, ed2k
– Support encryption, DHT, PEX and magnet link
– Upload and download bandwidth control
– Download scheduling
AiDisk file server
– Samba and FTP server with account management
IPTV support
Roaming Assist
OFDMA
Beamforming
Button
WPS Button, Reset Button, Power Switch
LED Indicator
Power x 1
2.4G x 1
5G x 1
LAN x 4
WAN x 1
Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 19 V with max. 1.75 A current
OS Support
Windows® 10
Windows® 8
Windows® 7
Mac OS X 10.6
Mac OS X 10.7
Mac OS X 10.8

Wi‑Fi Standard	802.11ax (WiFi 6), also backward compatible with 802.11a/b/g/n/ac.
Bands & Speed	Dual‑band: 2.4 GHz + 5 GHz. Up to ~574 Mbps (2.4 GHz) and ~2402 Mbps (5 GHz). Combined AX3000 performance.
Antennas	4 external antennas for improved range and signal strength.
Processor & Memory	1.5 GHz tri‑core CPU, 256 MB Flash + 512 MB RAM.
Connectivity / Ports	1 × Gigabit WAN, 4 × Gigabit LAN ports, 1 × USB 3.2 Gen 1 port.
Coverage / Use-case	Suitable for large homes / multi‑device households. Also compatible with mesh setups (via ASUS AiMesh) for whole‑home WiFi.
Advanced WiFi Features	Uses OFDMA + MU‑MIMO and 1024‑QAM modulation — helps handle many devices simultaneously with lower latency and better efficiency.
